High Pressure Silicone Braided Hose: Pressure Ratings, Materials, and Selection Guide

High pressure silicone braided hose is widely used in industrial pump systems, beverage equipment, medical devices, and automated fluid transfer systems. However, many engineers and procurement specialists struggle with selecting the correct pressure rating, reinforcement structure, and compliance standards.

This guide explains the pressure capabilities, structural design, certification requirements, and selection criteria of high pressure silicone braided hose to help buyers choose a reliable solution for demanding fluid systems.

1. What Is High Pressure Silicone Braided Hose?

Definition

A high pressure silicone braided hose is a reinforced silicone tubing designed to withstand elevated internal pressure while maintaining the flexibility and thermal stability typical of silicone materials.

Unlike standard silicone tubing, this hose integrates a fiber reinforcement layer between silicone walls to increase structural strength.

Typical Hose Structure

Inner Layer

Food grade or medical grade silicone that comes into contact with the fluid.

Reinforcement Layer

High-strength fiber braid such as polyester or aramid.

Outer Layer

Protective silicone coating that enhances durability and environmental resistance.

Manufacturing Process

• Silicone raw material compounding
• Inner tube extrusion
• Fiber braid reinforcement
• Outer silicone extrusion
• High-temperature vulcanization

In many regulated industries, platinum cured silicone braided hose is preferred due to its higher purity and lower extractables.

2. Pressure Performance of High Pressure Silicone Braided Hose

Working Pressure and Burst Pressure

The pressure capacity of silicone braided hose depends on diameter, wall thickness, and braid density.

• Working pressure: typically 5–15 bar
• Burst pressure: 15–45 bar

Burst pressure is typically 3–4 times higher than the working pressure. Pressure verification is often performed according to ASTM D1599 hydrostatic pressure testing methods.

Factors Affecting Pressure Rating

• Tube diameter
• Wall thickness
• Reinforcement braid density
• Silicone material formulation

3. Key Advantages of High Pressure Silicone Braided Hose

Wide Temperature Range

Most reinforced silicone hoses operate between -40°C and 200°C. Short-term temperature tolerance may reach 250°C depending on the silicone formulation.

Excellent Flexibility

Despite fiber reinforcement, silicone braided hose maintains strong flexibility, allowing it to perform well in compact equipment layouts and dynamic fluid systems.

High Chemical Stability

Silicone materials provide good resistance to water, ozone, UV exposure, and mild chemicals, enabling long-term operation in demanding industrial environments.

4. Main Types of Silicone Braided Hose and Applications

5. How to Choose the Right High Pressure Silicone Braided Hose

Step 1: Define Operating Conditions

• Working temperature
• Operating pressure
• Fluid type (water, oil, chemicals, steam)

Step 2: Verify Certification Requirements

• Food industry → FDA / LFGB
• Medical device → ISO 10993
• European market → REACH compliance

Step 3: Confirm Dimensional Specifications

• Inner diameter tolerance
• Wall thickness
• Minimum bend radius

Step 4: Evaluate the Manufacturer

• Production capacity
• Quality control system
• Pressure testing capability
• OEM customization experience

6. Frequently Asked Questions

What pressure can silicone braided hose withstand?

Typical industrial models operate at 5–15 bar working pressure, depending on hose diameter and reinforcement density.

Can silicone braided hose be used for hot liquids?

Yes. Most models support temperatures between -40°C and 200°C.

Is silicone braided hose food safe?

Food grade versions comply with FDA 21 CFR 177.2600 and LFGB regulations.

How long does silicone braided hose last?

High quality silicone braided hose can last 5–10 years under proper industrial conditions.

Conclusion

High pressure silicone braided hose combines flexibility, pressure resistance, temperature stability, and regulatory compliance. These properties make it essential in industrial fluid systems, beverage equipment, and medical devices.

Selecting the correct hose requires evaluating operating conditions, certifications, pressure ratings, and manufacturer reliability to ensure long-term performance and safety.
