Multicolor Side-Emitting Silicone Neon Flex

Side-emitting silicone neon flex, six sections from 4 x 9 mm to 16 x 17 mm, strip cavities of 5, 8 and 10 mm, translucent compound in a range of colours, platinum-cured silicone 70 +/- 5 Shore A, -40 to +200 C, coils up to 100 m.

    Product Features

    Silicone neon flex profile for top-view lines, 15 sections from 6 × 11 mm to 100 × 30 mm
    Strip cavities from 6 mm to 30 mm PCB, including a twin-strip 100 × 30 mm body
    Multi-colour variants: four colour zones in a 16 × 16 mm section, three on an edged 25 × 15 mm profile
    Platinum-cured translucent silicone, 70 ± 5 Shore A, −40 °C to +200 °C
    Light performance engineered per project: evenness confirmed on a sample of your strip
    IP67 or IP68 as a sealed assembly; coils up to 100 m; USD 500 minimum order value

    Application

    Channel letters
    Domed face and return profiles for illuminated letters.
    Signage and lightboxes
    Even edges on illuminated signs and boxes.
    Architectural accents
    Facade lines, canopies and entrance details.
    Retail displays
    Shelf edges, counters and display outlines.
    Hospitality interiors
    Bar fronts, wall features and ceiling lines.
    OEM and private label
    Profiles quoted to a drawing for fixture makers.

  • Parameters

    Product Features

    Silicone neon flex profile for top-view lines, 15 sections from 6 × 11 mm to 100 × 30 mm
    Strip cavities from 6 mm to 30 mm PCB, including a twin-strip 100 × 30 mm body
    Multi-colour variants: four colour zones in a 16 × 16 mm section, three on an edged 25 × 15 mm profile
    Platinum-cured translucent silicone, 70 ± 5 Shore A, −40 °C to +200 °C
    Light performance engineered per project: evenness confirmed on a sample of your strip
    IP67 or IP68 as a sealed assembly; coils up to 100 m; USD 500 minimum order value

    Application

    Channel letters
    Domed face and return profiles for illuminated letters.
    Signage and lightboxes
    Even edges on illuminated signs and boxes.
    Architectural accents
    Facade lines, canopies and entrance details.
    Retail displays
    Shelf edges, counters and display outlines.
    Hospitality interiors
    Bar fronts, wall features and ceiling lines.
    OEM and private label
    Profiles quoted to a drawing for fixture makers.

The light leaves through the side, so the line can be thin

Extruded silicone neon flex that emits through a narrow side face. The strip sits in a cavity inside the profile, and the side wall does the diffusing, which keeps the visible line slim and the fixture shallow.

6 side-emitting sections, 4 × 9 to 16 × 17 mmTranslucent compound in a colour range−40 °C to +200 °CCoils up to 100 m
Multicolour side-emitting silicone neon flex profiles in red, blue, yellow, green, orange and white

What a side-emitting silicone neon flex is

Side-emitting means the light leaves the profile through one narrow face rather than through a wide top. The strip runs in a cavity inside the silicone, parallel to that face, and the silicone wall between them diffuses the output into a thin line.

The shape is what makes it useful for the places a top-view profile will not go: a slim letter return, the edge of a counter, a groove cut into a wall, a line that has to sit flush against the surface it lights. Side-emitting also keeps the lit line narrow, which is often what a designer wants and what a standard sleeve cannot deliver.

Six sections cover the range, from a 4 × 9 mm detail profile to a 16 × 17 mm body for longer runs. Colour here is a compound decision as much as an optical one: the profile can be opal, translucent, or tinted to a colour sample, and the multi-colour variants carry more than one tone. If you need a wide top face instead, the top-view neon flex for channel letters is the other side of the same family.

Three affiliated companies, one silicone chain

Extrusion is the last step of a chain we control from the compound up. The three companies below are affiliated; each does what it is set up for, and Yutian handles the profile you buy.

Guilin Yutian New Materials

silicone raw materials and auxiliary materials

Dongguan Huahong Rubber & Plastic Material Co., Ltd

compound development and mixing

Dongguan Yutian Silicone Rubber Technology Co., Ltd

extrusion, finishing and packing in our 6,800 m² plant in Changping, Dongguan

Why buyers place the profile with us

Compound in our own hands

Transmittance, colour and flexibility come from the compound. Because we compound and extrude, a change in the light effect is a formulation change, not a new supplier.

Extrusion from your drawing

We work from the section drawing or the groove you have to fill, and tell you whether an existing die fits or a new one is needed.

Finishing and accessories

Cut to length and packed to suit your line. Where the fixture needs a sealed end, the method is agreed before the order.

Paperwork that matches the claim

Certificates are described at the level they are held. Where a product-specific test report is needed, it is quoted as a separate project instead of implied.

Key advantages

A thin line, by geometry

The emitting face is the narrow side of the profile, so the run reads as a fine line of light rather than a wide band. That is why it is used where the fixture should almost disappear.

Slim sections for tight detail

From 4 × 9 mm. Six sections cover letter returns, edges and routed grooves where a round tube or a top-view profile is simply too large.

Colour in the compound

Opal, translucent and tinted compounds are available, and the multi-colour variants put more than one tone in one profile. Colour is matched to a physical sample, not to a screen image.

Silicone for heat and weather

−40 °C to +200 °C, stable under the heat inside the cavity and under sunlight, with the flexibility to follow a curve instead of being jointed.

Bends along the run

The profile follows the curve of the sign or the detail it is mounted on. The safe radius depends on the section, so it is confirmed against the drawing before production.

No optical figure published

What the line looks like depends on the strip, its LED pitch, the cavity and the compound. We measure the approved sample and let that be the reference, instead of quoting a percentage measured on a different strip.

Sealed as an assembly

Solid silicone profile; where the fixture needs a rating the assembly is sealed to IP67 or IP68, with the end treatment agreed per project.

Converted before it ships

Coils up to 100 m or cut lengths, packed to suit your line.

Side-emitting sections in the range

These are the side-emitting sections in the range. The outside size decides how the profile sits; the cavity decides which strip goes in. Sizes are as stated in our section list.

SectionW × H (mm)Strip cavityTypical use
04094 × 95 mmHairline detail, small letter returns
06126 × 128 mmSlim letters and logo outlines
08168 × 168 mmSignage edges and counter lines
101810 × 1810 mmWider runs, wall grooves
122012 × 2010 mmLong facade lines and cove detailing
161716 × 1710 mmDeep sections for larger runs

If the section you need is not here, it is a die project: send the drawing and we will quote the tooling before anything is cut.

Side-emitting and top-emitting compared

Side-emitting and top-emitting profiles solve different problems, and the range includes both. The table is how we explain the choice; the section drawing usually decides it.

Side-emitting (this page)Top-emitting
Where the light leavesThrough the narrow side wallThrough the full top face
Lit lineThin, bright, directionalWide, soft, even
Section depthSlim: 9–17 mm in this rangeDeeper bodies with larger cavities
Best forSlim returns, edges, grooves, flush detailsLetters, panel edges, larger signs

Technical specification

PropertyValue
MaterialPlatinum-cured silicone, translucent or opal
Hardness70 ± 5 Shore A
Density1.2 ± 0.1 g/cm³
Tensile strength≥ 8 MPa
Elongation at break≥ 300 %
Tear strength≥ 30 kN/m
Service temperature−40 °C to +200 °C
FlammabilityUL94 HB (raw material)
Sections6 side-emitting sections, 4 × 9 mm to 16 × 17 mm
Strip cavity5 mm, 8 mm and 10 mm PCB width
ColourOpal, translucent or tinted compound; multi-colour variants on request
Coil and cut lengthCoils up to 100 m, or cut to length
SealingIP67 or IP68 as a sealed assembly, agreed per project

Mechanical values describe the compound we extrude. Optical behaviour and colour fidelity are set per project and confirmed on a sample, not published as catalogue numbers.

Applications

Where this profile earns its place:

Channel letters

Slim face and return profiles for illuminated letters.

Architectural outlines

Wall grooves, edge details and facade lines.

Retail displays

Counter edges, shelving accents and plinths.

Hospitality

Bar fronts, cabinetry and low-glare feature lines.

Creative signage

Thin coloured lines in shaped and curved signs.

Outdoor accents

Lines where sun and heat both apply.

Made to your specification

A profile is specified by five things. Send them together and the quotation comes back with a section that already fits them, or with the reason it does not.

  • The section — a drawing, or the outside size and the strip cavity you need.
  • The strip — PCB width and LED pitch, so the cavity and the bend radius can be checked.
  • The colour — a physical colour sample is the only reliable reference for a tinted compound.
  • The run — coil or cut lengths, and the curve the profile has to follow.
  • The quantity — metres per order and per shipment.

Where a colour is still open, we build a short sample run and match against it rather than against a screen.

Samples and lead time

Stock samples: free

Samples of standard stock items are sent free of charge, usually dispatched within 3 days.

Custom runs: quoted

A run in your compound, section or cut length is quoted with the project, including any die.

Production lead time

Standard items 5–7 days. Custom items 10–20 working days after sample approval.

Certificates and quality

The certificates below cover our compounds and our management system. They do not mean that every finished profile has been individually tested; a product-specific test report is a separate project and is quoted as one.

StandardWhat it coversLevel
ISO 9001:2015Quality management systemCompany level
ROHSRestricted substancesRaw-material level
REACHSubstance registrationRaw-material level
UL94 HBFlammability of the compoundRaw-material level
Class 100,000 cleanroomProduction environmentIn use

Monthly inspection pass rate is 95% or higher and batch acceptance pass rate is 99%.

Frequently asked questions

What does side-emitting mean in practice?

The light leaves the profile through one narrow face. The strip sits in a cavity parallel to that face, so the lit line is thin and directional instead of a wide band across the top of the profile.

How do the colours work — is the strip coloured?

Two things can carry colour: the compound of the profile and the strip you fit. We extrude opal, translucent and tinted profiles and can run multi-colour variants; the emitted colour of a tinted profile also depends on the strip behind it.

Can you match a specific colour?

Send a physical sample, a painted chip or a letter sample. We match the compound against it and confirm on a short run, because a screen image and a backlit silicone wall never read the same.

Is this for RGB or addressable strips?

The profile is passive silicone: it diffuses whatever the strip emits. Whether the line changes colour or animates is decided by the strip you choose, not by the profile.

Which section fits my strip?

The cavity decides it: 5 mm, 8 mm or 10 mm PCB in this range. Send the strip width and we will name the sections that fit, and check the bend radius you need.

Do you publish transmittance or uniformity values?

No. They depend on the strip, the cavity and the compound, so we measure the approved sample and use that as the reference for the project.

Is it waterproof?

The profile is solid silicone. Where a fixture needs a rating, it is supplied as a sealed assembly rated IP67 or IP68, with the end treatment agreed per project.

What are the order terms?

Minimum order value USD 500. Stock samples are free; custom runs are quoted. Standard items ship in 5–7 days, custom items in 10–20 working days after sample approval.

Related silicone LED parts

The other silicone LED parts we make, and the guides that explain how the formats differ:

Browse the full LED silicone parts category for sleeves, profiles, neon flex and accessories.

Send the colour sample and the strip you plan to fit

A physical colour sample and the strip width are what we need to propose a section and run a short sample. Tell us where the line sits; we will tell you which section keeps it thin.

salesmanager@yutiansilicone.com · Mobile / WhatsApp +86 180 2892 1514
DongGuan Yutian Silicone Rubber Technology Co., Ltd
Room 801, Building 10, No. 2, Tutang Industrial 2nd Heng Road, Changping Town, Dongguan City, Guangdong Province, China
